Mooney viscometers are core instruments for measuring viscous flow of polymer and master batch testing
which incorporates the latest measurement technology for the traditional Mooney viscosity,
Mooney scorch, and stress relaxation measurement in the rubber industry.
MyungJi Tech MV-2020 will enable stable and consistent compound quality.
Our latest software enables straightforward display of results, and data can be stored
and easily managed on the instrument PC.
MODEL
MV-2020
POWER
AC 220V 60Hz (50Hz : Option)
ELECTRICAL POWER
1.3KW
MOVEMENT
Geared motor Operation
TEMP. RANGE
Ambient temp. +10 ~ 200°C (230°C : Option)
TEMP. CONTROL
Digital P.I.D Control
TEMP. PROBE
PT 100Ω
COMPRESSED AIR
4㎏/㎠(4.1bar, 60psi)
CONTROLLED BY
Windows OS MDRA Software
ACCESSORIES INCLUDED
Air regulator, O-ring, Sample remover(Brass brush, Brass bar),Operation manual, Cable, Program CD, Extra fuse, Height gauge
STANDARD
ASTM D1646, KS M ISO289
DIMENSIONS
544(W) × 590(D) × 1,305(H) mm
WEIGHT
Approx. 110kg
ROTOR SPEED
2 RPM ± 0.01
Software
